LAB.Gruppen PLM 12K44-BP

R139,995.00 Incl.

Out of stock

SKU: LABPLM12K44 Categories: ,


12,000 Watt Amplifier with 4 Flexible Output Channels, LAKE Digital Signal Processing and Dante Digital Audio Networking for Touring Applications. 12,000 Watt amplifier with 4 flexible output channels and up to 5,900 Watts channel output for touring applications LAKE digital signal processing for unparalleled loudspeaker management and system control Integrated Dante* digital audio networking with up to 8 dual redundant input channels 4 x 3,000 Watts into 2 Ohms, 4 x 3,000 Watts into 2.67 Ohms, 4 x 3,000 Watts into 4 Ohms, 4 x 1,900 Watts into 8 Ohms, 4 x 950 Watts into 16 Ohms, 4 x 3,000 Watts into Hi-Z 70 V, 4 x 3,000 Watts into Hi-Z 100 V Proven and reliable Class-TD output stage with proprietary Intercooler high-efficiency cooling system Rational Power Management (RPM) provides total flexibility to allocate available power across all 4 output channels Best-in-class Power Factor Correction (PFC) with Current Draw Modelling reduces running costs and minimizes environmental impact Under-Voltage Limiting (UVL) for continued operation during severe mains supply voltage drops Dedicated on-board surveillance and load monitoring for complete peace of mind Redundant audio inputs and on-board system surveillance for full system security Backlit, white-on-black front panel display and menu navigation buttons 100 user presets for simple and efficient system configuration and set-up 3 front-to-rear airflow fans with temperature control for optimal speed and reduced noise 4 “LAKE Class” analog input channels with Iso-Float ground isolation 4 input channels of AES/EBU (AES3) digital audio supporting all standard sample rates up to 192 kHz with 24-bit resolution 2 Neutrik etherCON* RJ-45 ports provide dual redundant Dante interfaces and remote configuration via LAKE Controller and Dante Controller software Balanced analog and AES/EBU audio inputs and analog link outputs on Neutrik XLR* connectors 1 NLT8 and 2 NLT4 Neutrik speakON* output connectors Detachable Neutrik powerCON* cable rated at 250 V / 32 A Removable dust filter grilles for increased air circulation Rugged 2U rackmount chassis for durability in touring applications 10-Year Warranty Program* Designed and engineered in Sweden

Additional information

Weight 18 kg
Dimensions 48 × 43 × 10 cm
