An unbeatable Multi-Position PA System All-in-One Battery Powered Sound Great anywhere with this ultra portable Multi-Position PA System. Designed specifically for musicians, DJs, and general PA use, the ATLANTIS Series is the ultimate all-in-one PA, floor monitor, practice amplifier and primary music system. Multiple positions, supported by Auto EQ, ensure that you always sound your best. And with a 3-channel mixer, reverb, Bluetooth streaming and Mic/Guitar switch onboard, the ATLANTIS Series is ready to be your go anywhere Ultra Portable PA System. The versatile ATLANTIS Series speaker operates in five unique modes. With Auto EQ, the system automatically updates to maintain optimum tonal balance for each position. Use the examples below to quickly identify the best mode for your application. System Configurations Elevated Surface Position the speaker on a surface. This projects sound clearly and evenly throughout the audience, and ensures that audience members enjoy the full frequency range of the system. Tilt-Back For performances where your audience is close to you, tilt the ATLANTIS speaker onto its back edge. For best results, the performer should stand or sit to one side of the loudspeaker to avoid blocking sound from the audience. Monitor To use the ATLANTIS speaker as a personal floor monitor, place it on the ground horizontally, in front of and pointing toward the performer. Tilt the loudspeaker onto its side edge. Speaker Stand Place one or two ATLANTIS speakers on speaker stands (sold separately) for general-purpose sound reinforcement. Wall Mount Thanks to the wall mount optional accessories (standard F35), the ATLANTIS speaker can be mounted on a wall for permanent installations for home and movie theatres, churches, meeting halls etc.
Model No. ATLANTIS-PA6 ATLANTIS-PA8 Type An Unbeatable Active Multi-position PA System All-in-One Battery Transducer LF 1 * 6.5? subwoofer, 1? voice coil 1 * 8? subwoofer, 1? voice coil Transducer HF 3 * 2.75?, neodymium magnet, 1? voice coil Frequency Response (-6dB) 65 Hz – 18 kHz (-6dB) 50 Hz – 19 kHz SPL (1W/1m) (1m, free space) 93 dB (1m, free space) 95 dB Max. SPL (1m, free space) 110 dB (1m, free space) 120 dB Protection Circuits Short Circuit overdrive protection Impedance 4Ohms Amplification 2 x Class D Power Output (RMS) (RMS) 100W (RMS) 120W Power Output (Peak) (RMS) 200W (RMS) 240W Number of Mixer Channels 3 3 Number of Mic Preamps 2 2 EQ 2-Band Channel EQ Effects Reverb Inputs 2 * XLR / 6 .3mm Combo , / 1 * RCA Line in Outputs 1 * XLR line out Bluetooth Yes Enclosure Material Polypropylene Plastic Mounting Options 35mm pole mount, Tilt-back, Floor Monitor Power Supply 110~240V 50/60HZ Battery Rechargeable Lithium—ion battery 5200mAH 7 Hours 100% power / 12 hours 50% power Dimensions (WxHxD) 220 X 320 X 205mm 327 x 505 x 415mm Gross Weight 7,2Kg 8,6Kg
