Roland V-1HD+ Video Switcher

Portable Video Switcher for HD Video Productionf

Roland V-1HD+ Video Switcher

R20,995.00 Incl.

SKU: ROLV1HDVS Categories: ,

Description

Switch, Mix, and Create Like a Pro

The V-1HD+ is the ultimate compact A/V switching solution for serious visual storytellers. Elevate your creative production process with versatile I/O, a familiar user interface, deep control, and essential monitoring tools that help keep your content looking great and sounding perfect. The V-1HD+ delivers the superior performance you want and the production-critical reliability you demand—plus the Roland support and training resources you deserve.

Experience the plus advantage—upgrade your productions with the V-1HD+ today!

General

The V-1HD+ features PGM and PST busses, as well as a transition/fade bar (T-bar), which are industry-standard video switching controls. Tactile audio volume knobs, signal/peak lights, and unity gain markers enable intuitive sound level adjustments on the fly.

HD Switcher

This compact HD switcher has four HDMI inputs, supporting HD video and PC resolutions. Each input incorporates a frame buffer/TBC that allows you to use non-genlocked cameras and as play-out devices as video sources. You select the broadcast system (59.94/50 Hz) within the menu.

Audio Mixer

The built-in 14-channel audio mixer allows you to de-embed audio from the HDMI stream, mix, and re-embed the audio into your output stream. In addition to the embedded audio, the V-1HD+ supports analog audio input via two 3-pin XLR, a left/right pair of RCA connectors, and a 3.5mm stereo mic input.

Audio

Each audio input has its own three-band equalizer, high-pass filter, compressor, and noise gate, plus a sync delay to align audio with video if needed. The XLR and 3.5mm inputs also include de-essers to clean up vocal sounds in real time. The built-in limiter, three-band equalizer, and compressor on the main outputs enable you to deliver broadcast-quality sound over the analog audio outputs.

Live Stream

You can record or live stream the output of the mixer by connecting to a computer

Control Buttons

The soft-rubber backlit buttons allow you to easily see the condition of your switcher, even in dim lighting conditions. The V-1HD+ features the standard source, preview, mix, cut, and auto buttons, fader bar, and fade in/out knob, as well as four physical memory buttons that allow you to quickly choose up to eight presets for stills and effects sources.

Recording

The unit has a record control button that allows you to start and stop recording to select Atomos recorders via HDMI.

Four-Layer Effects Engine

The V-1HD+ supports up to four composition layers, making it simple to add lower-third titles, logos, social media comments, and more for a polished professional output that will keep the attention of your audience.

Keying

The keying functionality permits picture-in-picture, as well as green screen and graphics keying.

Video Effects

Transition: Cut, mix (dissolve/FAM/NAM), Wipe (8 types)
Composition: PiP (square, circle, diamond), split (2 types), keyer (luminance, chroma), DSK (luminance, chroma)
Other: Flip horizontal, flip vertical, still image capture, still image playback, output fade (audio, video: white or black), test pattern output

Memory

The memory button allows you to save or recall up to eight presets, and the Freeze button can temporarily pause the incoming video.

Panel Buttons

These buttons can be used to switch your video instantly or for applying effects.

Transitions

The T-bar lets you control the speed of your selected transitions.

Still Image

The switcher can store up to four files in its internal memory and supports the following still image formats:

  • Bitmap file (.bmp): Maximum 1920 x 1080 pixels, 24-bit color, uncompressed
  • PNG file (.png): Maximum 1920 x 1080 pixels, 24-bit color (PNG alpha channel not supported)

Audio Effects

Delay
High-pass filter
De-esser
Compressor
Noise gate
Equalizer
Limiter
Reverb
Test tone output

Additional Functions

Preset memory (8 types)
Panel lock function
EDID emulator
Automatic switching
Automatic input detect

VIDEOVideo Processing4:2:2 (Y/Pb/Pr), 8-bitInput ConnectorsINPUT 1–3: HDMI type A x 3
*HDCP Supported

INPUT 4: HDMI type A
* HDCP Supported
* Multi-format SupportedOutput ConnectorsOUTPUT 1–2: HDMI type A x 2
* HDCP SupportedInput FormatsINPUT 1–3
720/59.94p, 720/60p *1, *3
720/50p *1, *4
1080/59.94i, 1080/60i, 1080/59.94p, 1080/60p, 1080/29.97p, 1080/30p *2, *3
1080/50i, 1080/50p, 1080/25p *2, *4
1080/23.98p, 1080/24p *2
* The input interlaced video signal is converted to progressive video signal by internal processing.
*1 SYSTEM FORMAT = 720p
*2 SYSTEM FORMAT = 1080i or 1080p
*3 FRAME RATE = 59.94 Hz
*4 FRAME RATE = 50 Hz

INPUT 4
480/59.94i, 480/59.94p, 720/59.94p, 720/60p, 1080/59.94i, 1080/60i, 1080/59.94p, 1080/60p, 1080/29.97p, 1080/30p *1
576/50i, 576/50p, 720/50p, 1080/50i, 1080/50p, 1080/25p *2
1080/23.98p, 1080/24p
VGA (640 x 480/60 Hz), SVGA (800 x 600/60 Hz), XGA (1024 x 768/60 Hz)
WXGA (1280 x 800/60 Hz), SXGA (1280 x 1024/60 Hz)
FWXGA (1366 x 768/60 Hz), SXGA+ (1400 x 1050/60 Hz)
UXGA (1600 x 1200/60 Hz), WUXGA (1920 x 1200/60 Hz)
* The refresh rate is the maximum value of each resolution.
* Conforms to CEA-861-E,VESA DMT Version 1.0 Revision 11.
* 1920 x 1200/60 Hz: Reduced blanking
* The input interlaced video signal is converted to progressive video signal by internal processing.
*1 FRAME RATE = 59.94 Hz
*2 FRAME RATE = 50 Hz

Still Image:
Bitmap File (.bmp) Maximum 1920 x 1080 pixels, 24-bit color, uncompressed.
PNG File (.png) Maximum 1920 x 1080 pixels, 24-bit color
* It can store up to 4 files in the internal memory.
* PNG alpha channel not supported.Output FormatsOUTPUT 1–2:
720/59.94p *1, *4
720/50p *1, *5
1080/59.94i *2, *4
1080/50i *2, *5
1080/59.94p *3, *4
1080/50p *3, *5
*1 SYSTEM FORMAT = 720p
*2 SYSTEM FORMAT = 1080i
*3 SYSTEM FORMAT = 1080p
*4 FRAME RATE = 59.94 Hz
*5 FRAME RATE = 50 HzVideo EffectsTransition: CUT, MIX (DISSOLVE/FAM/NAM), WIPE (8 types)
Composition: PinP (SQUARE, CIRCLE, DIAMOND), SPLIT (2 types), Keyer (Luminance key, Chroma key), DSK (Luminance key, Chroma key)
Other: Flip horizontal, Flip vertical, Still image capture, Still image playback, Output fade (Audio, Video: WHITE or BLACK), Test pattern outputAUDIOAudio ProcessingSample rate: 24 bits/48 kHzAudio formatsLinear PCM, 24 bits/48 kHz, 2 chInput ConnectorsINPUT 1–4: HDMI Type A x 4
AUDIO IN 1–2: XLR-3-31 type (balanced, phantom power DC 48 V, 14 mA Max)
LINE IN: RCA phono type
MIC/AUX IN: Stereo miniature phone type (PLUG-IN power)Output ConnectorsOUTPUT 1–3: HDMI Type A x 2
AUDIO OUT L, R: 1/4-inch TRS phone type
PHONES: Stereo miniature phone typeNominal Input LevelAUDIO IN 1–2: -60 to +4 dBu (Maximum input level: +24 dBu)
LINE IN: -10 dBu (Maximum input level: +10 dBu)
MIC/AUX IN: -51 to -10 dBu (Maximum input level: +10 dBu)Input ImpedanceAUDIO IN 1–2: 10 k ohms
LINE IN: 15 k ohms
MIC/AUX IN: 10 k ohmsNominal Output LevelAUDIO OUT L, R: +4 dBu (Maximum output level: +24 dBu)
PHONES: 72 mW + 72 mW (32 ohms load)Output ImpedanceAUDIO OUT L, R: 600 ohms
PHONES: 10 ohmsAudio EffectsDelay, High pass filter, De-Esser, Compressor, Noise gate, Equalizer, Limiter, Reverb, Test tone outputOTHERSOther ConnectorsUSB MEMORY: USB A type (for USB flash drive)
REMOTE: USB B type (for remote control)
RS-232: DB-9 type (male, for remote control)
TALLY: DB-9 type (female, for TALLY output)Other FunctionsPreset memory (8 types)
Panel lock function
EDID emulator
Auto switching
Auto input detectPower SupplyAC adaptorCurrent Draw2.1 APower Consumption25.2 WOperation Temperature+0 to +40 degrees Celsius
+32 to +104 degrees FahrenheitDimensions316 (W) x 121 (D) x 65 (H) mm
12-1/2 (W) x 4-13/16 (D) x 2-9/16 (H) inchesWeight (excluding AC adaptor)1.4 kg
3 lbs 2 ozAccessoriesStartup Guide
Leaflet “USING THE UNIT SAFELY”
AC adaptor
Power cord

* 0 dBu = 0.775 Vrms



Additional information

Weight 2.5 kg
Dimensions 42 × 23 × 17 cm
