Description

A VERSATILE AND COMPACT SWITCHER WITH MULTI-SCREEN OUTPUT AND VIDEO COMPOSITING. A MULTI-FORMAT MATRIX SWITCHER WITH SCALERS THAT SUPPORTS UP TO FULL HD.

MAIN FEATURES A table-top matrix switcher that’s the width of a 13″ laptop, equipped with four HDMI inputs and outputs High-quality 4:4:4/10-bit processing at up to WUXGA/1080p Frame synchronizer and scaler on all inputs Three operation modes Matrix Mode allow switching of 4 sources to any of 4 outputs Switcher Mode allows PinP, key-compositing, and dissolve transitions Split Mode allows PinP of up to three inset windows Built-in eight-channel digital audio mixer handles audio from four HDMI signals and stereo analog input Built-in EDID emulator, and HDCP-compliant Still images can be loaded from a USB flash drive. Processing4:4:4 (Y/Pb/Pr, RGB) /10 bits 4:2:2 (Y/Pb/Pr) /10 bitsInput ConnectorsHDMI : HDMI type A x 4 (HDMI INPUT 1–4) *HDCP SupportedOutput ConnectorsHDMI : HDMI type A x 4 (HDMI OUTPUT 1–4) *HDCP SupportedFormats480/59.94i (*1), 576/50i (*1), 480/59.94p (*1), 576/50p (*1), 720/59.94p, 720/50p, 1080/59.94i, 1080/50i, 1080/59.94p, 1080/50p, 800 x 600/60 (*1), 1024 x 768/60 (*2), 1280 x 720/60 (*2), 1280 x 800/60 (*2), 1366 x 768/60 (*2), 1280 x 1024/60 (*2), 1400 x 1050/60 (*2), 1600 x 1200/60, 1920 x 1080/60, 1920 x 1200/60 RB *Conforms to CEA-861-E,VESA DMT Version 1.0 Revision 11 *Frame rate is 59.94 Hz (NTSC) or 50 Hz (PAL). (*1) Input only. (*2) Output refresh rate is 75 Hz when frame rate is set to 50 Hz.EffectsOutput Mode : Switcher, Split, Matrix Transition : Mix, Cut (*3) Composition (Keyer) : 1 (*3) Others : HDCP Supported, Test Pattern Generator. (*3) These effects depends on Output Mode.Still ImageInternal Memory : 1 Maximum Size : 1920 x 1200 pixels Format : Windows Bitmap File (.bmp) 24 bit per pixel, uncompressedAUDIOSampling Rate24 bits/48 kHzInput ConnectorsHDMI : HDMI type A x 4 AUDIO INPUT : RCA pin typeOutput ConnectorsHDMI : HDMI type A x 4 AUDIO OUTPUT : RCA pin type PHONES : Stereo mini typeInput LevelAUDIO INPUT : -10 dBu (Maximum : +8 dBu)Input ImpedanceAUDIO INPUT : 15 k ohmsOutput LevelAUDIO OUTPUT : -10 dBu (Maximum : +8 dBu) PHONES : 72 mW + 72 mW (32 ohms)Output ImpedanceAUDIO OUTPUT : 1 k ohm PHONES : 10 ohmsFormatsHDMI : Linear PCM, 24 bits, 48 kHz, 2 chProcessingMixer : 4 ch (Delay : Maximum 500 ms, Audio Follow) Test Tone GeneratorOTHERSExternal ConnectorsREMOTE : RS-232 DB-9 type (Male) x 1 *for Remote Control USB MEMORY : USB A type x 1 (USB Memory)Preset Memory16 *Auto Memory FunctionPower SupplyAC AdaptorCurrent Draw2.1 APower Consumption25 WOperation Temperature+0 to +40 degrees Celsius +32 to +104 degrees FahrenheitDimensions328 (W) x 117 (D) x 57 (H) mm 12-15/16 (W) x 4-5/8 (D) x 2-1/4 (H) inchesWeight1.2 kg 2 lbs 11 ozAccessoriesOwner’s Manual AC adaptor Power cord.
